MODEL : BFW-BMV 45 TC24 - TRAVEL
Machine
X - Axis 600 MM
Y- Axis 450 MM
Z- Axis 500 MM
Table Size 900 x 450
Spindle R.P.M. 8000
Power 7.5 / 5.5 KW
Auto Tool Change 24 Tools
Spindle Taper BT-40
System Fanuc-Oi MB
Additional Features
  • Chip Conveyor
  • Spindle Thro Coolent
  • 4th Axis Facility
UCAM Make
    Dia 200 MM
MODEL : LEBNOND MAKINO FNC60 - TRAVEL
Machine
X - Axis 600 MM
Y- Axis 400 MM
Z- Axis 400 MM
Table Size 800 x 450
Spindle R.P.M. 6000
Power 7.5 / 5.5 KW
Auto Tool Change 20 Tools
Spindle Taper BT-40
System Fanuc-O M

MODEL : CNC LATHE
Machine
CNC LATHE
MAKE
MODEL
GALAXY
MIDAS 6
SPECIFICATION Unit Size
CAPACITY
Max.turning Dia mm 240
Max.turning Length mm 365
Chuck dia, max mm 200
SPINDLE
Spindle speed range rpm 40-4000
Spindle Motor power
(30min./cont.)
kw 5.5/7.5
TRAVEL
Cross travel (X-axis) mm 140
Longitudinaltravel (Z-axis) mm 365
TURRET
Turret type (SERVO/EM)   EM
Turret tool stations No 8
Tool shank size mm 25*25
Boring bar dia, max mm 40
MODEL : BFW-BMV 35 TC20 - TRAVEL
Machine
X - Axis 450 MM
Y- Axis 350 MM
Z- Axis 350 MM
Table Size 600 x 350
Spindle R.P.M. 8000
Power 5.5 KW
Auto Tool Change 20 Tools
Spindle Taper BT-40
System Fanuc-Oi MB

MODEL : BFW-BMV 51 TC24 - TRAVEL
Machine
X - Axis 800 MM
Y- Axis 510 MM
Z- Axis 510 MM
Table Size 1000 x 510
Spindle R.P.M. 8000
Power 11 KW
Auto Tool Change 24 Tools
Spindle Taper BT-40
System Fanuc-Oi MD

MODEL : JYOTI DX200 CNC LATHE
Machine
Cross travel (X-axis) 200 MM
Longitudinaltravel (Z-axis) 500 MM
Turret type (SERVO/EM) EM
Turret tool stations 8
Tool shank size 25 * 25mm
Boring bar Dia, Max+ 40mm
Max.turning Dia 350mm
Max.turning Length 500mm
Chuck dia, max 200mm
Spindle speed range 50-4000rpm
Spindle Motor Power (30min./cont.) 9-12kw
